Ashur Brick

Bricks Empowered by French Technology

info@ashurbrick.com

00964 770 7800 800

Common Brick

Currently in Production

Iraqi Common Brick Class A

75 mm (height) x 115 mm (width) x 240 mm (length)

Load Bearing Bricks

Currently in Production

200 mm (height) x 200 mm (width) x 400 mm (length)

Hollow Bricks

Currently in Production

200 mm (height) x 200 mm (width) x 400 mm (length)

Iraqi Common Brick Class A

Common Clay Building Brick adhering to the highest Iraqi Standard of 1988:25

CLASS A: This type of brick is used in partitions of buildings and load bearing foundations that is susceptible to erosion due to climate or nature or bricks of walls facing outside susceptible to erosion.

Dimension

Height x Width x Length

75 mm (height) x 115 mm (width) x 240 mm (length)

Hollowness

19 Holes

Percentage of holes is about 30% of the volume

Bearing Capacity

Compressive strength

> 200 kg/cm2 per brick equivalent to >20MPa.

Water Absorption Rate

Average water absorption is less than 16%

Efflorescence

salt on the surface of a brick material, where it forms a white coating.

Level of Efflorescence Low to None

Deviations (±)

Less than ±3% in Width Height and Length

Weight

2.5-2.6 kg per brick

Palletization

Number of Bricks per Pallet

400 bricks per pallet

Dimension and Weight of a pallet

Dimension 920 mm (height) x 975 mm (width) x 960 mm (length)
Weight 1,000kg-1,040kg per Pallet

Wall

Number of Bricks per square meter of wall

96 bricks per sqm- on 240mm length
48 bricks per sqm- on 115mm length

Fire Resistance

Period (minutes)

240 minutes

Firing at 900 C

Thermal Insulation

U-Value

0.45 W/(m²K)

Sound Insulation

Rw (dB)

40dB

Common Brick

Load Bearing Brick 200 mm (width)

The Future of Construction

Ashur Brick Load Bearing Bricks are vertically perforated bricks utilizing the latest French technology in construction materials. Highly engineered bricks allowing you to build up to G+2 floors and save on Reinforced concrete costs. The concept of load bearing construction will enable an engineering revolution in the construction industry.

Dimension

200 mm (height) x 200 mm (width) x 400 mm (length)

Hollowness

Percentage of holes between 50% - 55% of the volume

Bearing Capacity

> 75 kg/cm2 per brick equivalent to >7.5MPa; each brick can withstand more than of 60 tons of load.

Water Absorption Rate

Average water absorption is less than 16%

Efflorescence

Level of Efflorescence Low to None

Deviations

Less than ±3% in Width Height and Length

Weight

13-14.5 kg per brick

Palletization

102 bricks per pallet

Palletization

Dimension 1200 mm (height) x 1200 mm (width) x 1200 mm (length)
Weight 1,326kg - 1,479kg per Pallet

Fire Resistance

240 minutes

Firing at 900 C

Thermal Insulation

U-Value

0.45 W/(m²K)

Sound Insulation

45dB

Load Bearing Brick

Hollow Brick (HB-200)

Hollow Brick Width 200mm

Hollow Bricks are advanced bricks produced using clay bricks ideal for non-load bearing construction. Hollow Bricks are light weight and easy to use and are ideal for partition walls of high rise buildings.

Dimension

Height x Width x Length

200 mm (height) x 200 mm (width) x 400 mm (length)

Hollowness

16 Holes

Percentage of holes is around 60% of the volume

Bearing Capacity

Compressive strength

Averagely more than 25kg/cm2 equivalent >2.5MPa.

Water Absorption Rate

Average water absorption is less than 16%

Efflorescence

salt on the surface of a brick material, where it forms a white coating.

Level of Efflorescence Low to None

Deviations (±)

Less than ±2% in Width Height and Length

Weight

kg per brick

11.5kg

Palletization

Number of Bricks per Pallet

102 bricks per pallet

Palletization

Dimension and Weight

Dimension 1200 mm (height) x 1200 mm (width) x 1200 mm (length)
Weight ~1150-1200 kg per Pallet

Wall

Number of Bricks per square meter of wall

12.5 bricks per sqm- on 200mm length

Fire Resistance

Period (minutes)

240 minutes

Firing at 900 C

Thermal Insulation

U-Value

0.4 W/(m²K)

Sound Insulation

Rw (dB)

42dB

Hollow Brick

Download Important Documents

List of Import Documents from Ashur Brick

Common Iraqi Brick Standard of IQS 25-1988

This document contains the required specification of common CLAY BRICK BUILDING as published in 1988 number 25 including requirement of Class A, Class B and Class C clay bricks

Methods of Sampling and Testing Clay building bricks Iraqi Standard IQS 24-1988

This document contains the sampling and testing method for common Iraqi bricks ( Dimension,Compressive Strength, Water Absorption, Efflorescence and more)

Sulaymaniyah Construction Laboratory Test Result of Ashur Load Bearing Bricks

Detailed Laboratory Report by Sulaymaniyah Construction Laboratory which is part of Ministry of Construction and Housing in Kurdistan Region of Iraq which shows the compressive strength (megapascal), water absorption % and dimension tests that all have been passed successfully by Ashur Brick Load Bearing Bricks.

University of Mosul Engineering Consulting Bureau Thermal Conductivity Result

Detailed Laboratory Report by the respected Engineering Consulting Bureau of Mosul University which is part of Ministry of Higher Education of Iraq which shows the thermal conductivity (U-Value) of Ashur Brick Common Brick, Load-bearing bricks and Hollow Bricks which is very important in determining the insulation capabilities of our bricks and walls created with our bricks.

COLOUR AND TEXTURE VARIATION

Our clay bricks are made from naturally occurring minerals that are kiln fired to lock in their colour and strength for life.
The composition of the raw materials as well as the firing process may cause each run to differ. The resulting colour and texture variation is inherent in the process and part of the appeal of our natural products.
The product images in our brochures and on this website give a general indication of colour for your preliminary selection.
We recommend you also view current product samples and look at actual finished projects before making your final selection.
